Quick Details

  • Resistanc: below 10e6ohm
  • Size: 355*315*580mm
  • NAME: SMT ESD Anti-static PCB Magazine Rack 3W-9805301A

Packaging & Delivery

Packaging Details: 50 pcs /wooden box, size: 1400*1110*1090mm /box, weight: 325kg /box
Delivery Detail: 3-5 working days

SMT ESD Anti-static PCB Magazine Rack

*3W-9805301A



Specifcation:





1)Size : 355*315*580mm

2)Max tolerant Temperature  : 80degree.C

3)Adjustable Width(mm):350*(80-250mm )

4)Base Material: plastic

5)Per.position:A=34,B=34

6)Pitch:10(mm)

7)PCB Slots:50

8)Weight(kg):5.0kg

9)Fix method: screw adjustment

10)Guaide slot of side plat.Depth: 3.5mm,   width:7mm

11)surface resistance: below 10E 6ohm



More Rack Choice :



Item No.Outer Dimensions(mm)PCB Adjust (L*W)Top& bottomRef. positionTemp.Fix method Side plate
 LWH  AB
3W-9805301A355315580355*(80-250mm)     plastic343480 deg. Cscrewwhole plate
3W-9805301A-1355315305355*(80-250mm)     plastic343480 deg. Cscrewwhole plate
3W-9805301B1355320563350*(50-250 mm) Metal343480 deg. Chandle/screwfive-piece  plate
3W-9805301B1G355320563350*(50-250 mm) Metal3434120 deg. Chandle/screwfive-piece  plate
3W-9805301B1H355320563350*(50-250 mm) Metal3434200deg.cscrewfive-piece  plate
3W-9805301B1-1355320363350*(50-250 mm) Metal343480 deg. Chandle/screwfive-piece  plate
3W-9805301B1-1G355320363350*(50-250 mm) Metal3434120 deg. Chandle/screwfive-piece  plate
3W-9805301B2355320565350*(50-250 mm) plastic343480 deg. Chandle/screwfive-piece  plate
3W-9805301B2G355320565350*(50-250 mm) plastic3434120 deg. Chandle/screwfive-piece  plate
3W-9805301B3355320563350*(50-250 mm) Metal343480 deg. Chandle/screwwhole plate
3W-9805301B3G355320563350*(50-250 mm) Metal3434120 deg. Chandle/screwwhole plate
3W-9805301B4355320565350*(50-250 mm) plastic343480 deg. Chandle/screwwhole plate
3W-9805301B4G355320565350*(50-250 mm) Metal3434120 deg. Chandle/screwwhole plate
3W-9805301C460400565460*(70-330mm) Metal343480 deg. Chandle/screwfive-piece  plate
3W-9805301CG460400565460*(70-330mm) Metal3437120 deg. Chandle/screwfive-piece  plate
3W-9805301D535460569525*(50-400mm)Metal343780 deg. Chandle/screwtwo-piece plate
3W-9805301DG535460569525*(50-400mm)Metal3437120 deg. Chandle/screwtwo-piece plate
3W-9805301E535530569530*(70-460mm)Metal343780 deg. Chandlefive-piece  plate
3W-9805301EG535530569530*(70-460mm)Metal3437120 deg. Chandlefive-piece  plate
3W-9805321355320560350*(50-250 mm) plastic343480 deg. Cchainwhole plate
3w-9805301F630530569630*(50-450mm)      Metal343780 deg. Cscrewtwo-piece plate
3w-9805301FG630530569630*(50-450mm)      Metal3437120 deg. Cscrewtwo-piece plate
3w-9805301Q355320563350*(50-250mm) Metal343480 deg. Chandlefive-piece  plate
3w-9805301QG355320563350*(50-250mm) Metal3434120 deg. Chandlefive-piece  plate
3w-9805301N400320573400*(50-255mm)                                         plastic3434120deg.CScrewwhole plate





 More angle photoes showing :



 ABOUT US

Company Information

SANWEI (3W) was established in 1988, which is a "National High-tech and innovation technology" company,and the researching & producing base of ESD anti-electrostatic equipment and material in China.
3W specialized in manufacturing a series of ESD products,such as ESD PCB Rack, ESD Circulation Rack which can tolerant temperature at 120 or 200°C,   ESD Box, ESD PCB Trolley  , ESD Safe Gloves,  Body Protection Products, Packing products, ESD Inspector and Tester, Clean and Dust Free Products so on,which are all in accordance with American military technical standards, GJB and ISO 9000 system, ISO 14001:2004, SGS and ROHS standards.



Now we are supplier of ERICSSON, MOTOROLA, LG, PHILIPS, NOKIA, BAXTER, SAMSUNG, PANASONIC, SHARP, KAGA ELECTRONICS, ASUS, BENQ, CSOT, TCL, FOXCONN, MIDEA, HAIER, ZTE, CHANGHONG,Our products directly export to Europe --- GERMANY, U.K., FINLAND, SPAIN, FRANCE, DANMARK, NORWAY, AUSTRIA, HUNGRAY, ROMANIA, UKRAIN, RUSSIA FEDERATION. Asia--- KOREA, MALAYSIA, SINGAPORE, THAILAND, PHILLIPINES, INDIA. America--- U.S.A. , CANADA, BRAZIL, ARGENTINA.
